1607060000

WEIDMULLER  1607060000  针座, 3.5MM, 直角型, 4路

The is a 4-pole black Terminal Block Header with THT solder connection and 90° outgoing elbow. The SL 3.50/04/90F 3.2SN OR BX header has tinned CuSn contact with PBT insulation. It is pin header for wave soldering in 3.50mm pitch and plugging direction is parallel to the PCB with screw flange housing variant.

.

Safe from back-of-hand touch

.

IP10 Protection

.

UL94V-0 Flammability rating

.

-50 to 100°C Operating temperature range
