工业圆形,公, 2路, 电缆
Solder Cup Contacts, 0.530 in. Connector Diameter, Filed Installable Cable End Connectors
Contact arrangements shown are wiring view of cable end pins/sockets. Key/Keyway shown for orientation only.
* Provide Quality Solutions Requiring Interconnection in Harsh Environments
* 2-31 Contacts Available
* Applications Include, But Not Limited to, Marine, GPS Systems, Transportation, Etc.
* Ratings: 3.0 to 7.5 A, 600 V
* Contact Plating: Gold Over Nickel
* Mechanical Specifications: Minimum of 300 Mate/Unmate Cycles, Overriding Locking Feature on Coupling Ring to Prevent Vibration or Loosening, and an All Series Hex Nut to Withstand 1-12 inch/lb. Tightening Torque
* Environmental Specifications: Temperature: -55°C to +125°C -67°F to +257°F, Corrosion: 300 Hour Salt Spray Contacts
* Cable O.D. Range: 0.15"-0.17"
