115C180

Electromechanical Relay 115VDC 115VAC 3A SPST-NC 28.58x28.58x69.85mm THT Time Delay Relay

Timing cycle begins upon application of power to the heater terminals. At the end of the initial delay time the relay contacts transfer and remain in a transferred state until input power is removed. When the heater input power is removed, the contacts transfer back to their original state at the end of a reset release delay period.

.

*Timing Selection:** Fixed delay times, up to 300 seconds. **Contact Rating:** 3 A @ 115 VAC. **Contact Form:** SPST form A NO or B NC. UL File #E96739M. **Operating Temperature:** –55°C to +80°C. **Mounting:** 8-Pin octal socket. **Expected Life @ 25°C:** 500,000 operations min. at rated loads. **Contact** **Material: **Silver-Cadmium Oxide.
