Edwards Signaling Products 105XBRMG24D XTRA-BRITE LED Adverse Location Signal Green 24V DC, 0.215A

The 105XBRM Series LED visual signals are heavy duty, reliable, UL, cUL General Utility misc. device/control unit accessory beacons. The 105XBRM Series features a UL listed Type 4X enclosure and is UL Listed for Marine Use. These signals are designed for use in industrial applications or in applications where a Type 4X enclosure is required. The 105XBRM LED series come in a steady-on mode, and can easily be set to a 65 fpm flashing mode. The base is manufactured from glass-reinforced thermoplastic polyester resin and the double fresnel lens is made of shatter resistant polycarbonate.

**Features**

* Available in 24 VDC or 120 VAC

* Panel, Conduit or Surface Mount

* Immune to Shock and Vibration

* –31 to 150°F –35 to 66C Operating Temperature

* UL Listed NEMA Type 4X Housing and Marine Rated

* UL Listed for Class I, Division 2, Groups A, B, C and D, Class II, Division 2, Groups F and G and Class III Location

105XBRMG24D中文资料参数规格
技术参数

电源电压DC 24 V

额定电流 215 mA

工作温度Min -35 ℃

电源电压 24 VDC

封装参数

安装方式 Base

外形尺寸

长度 121 mm

高度 121 mm

物理参数

颜色 Green

数据手册

在线购买105XBRMG24D
型号: 105XBRMG24D
制造商: Edwards Signaling
描述:Edwards Signaling Products 105XBRMG24D XTRA-BRITE LED Adverse Location Signal Green 24V DC, 0.215A
