TE CONNECTIVITY 1-1437719-3 圆形连接器外壳, 黄铜主体, TRIAD 01系列, TE - TRIAD 01 Series 5-1437720-6 Socket Contacts
电缆插头
3 或 5 路类型电缆插头,适用于 1A 或 3A 类型引脚或触点
### 注
有关合适的引脚触点,请参阅库存号 669-3021;有关合适的插座触点,请参阅库存号 669-3033
欧时:
3路 电缆安装 直向 圆形连接器
得捷:
CONN PLUG HSG FMALE 3POS INLINE
立创商城:
1-1437719-3
e络盟:
圆形连接器外壳, TRIAD 01系列, TE - TRIAD 01系列5-1437720-6插口触芯, 黄铜主体
艾睿:
A great way you can ensure a solid connection between your cylindrical cable housing is by using this shielded circular subminiature 1-1437719-3 connector from TE Connectivity. It has a plug type gender. This socket type connector has 3 socket type contacts. It has a straight body orientation. This device has a maximum current rating of 3 A. This product is 38 mm long with a diameter of 12 mm. This circular connector has an operating temperature of -40 to 80 °C. It uses the crimp termination method.
Allied Electronics:
TRIAD 01 Series; 3 Pole Cable Mount Subminiature Connector Socket; IP65
Chip1Stop:
Conn Shielded Circular Subminiature SKT 3 POS Crimp ST Cable Mount 3 Terminal 1 Port
Verical:
Conn Circular SKT 3 POS Crimp ST Cable Mount 3 Terminal 1 Port
Newark:
# TE CONNECTIVITY 1-1437719-3 Circular Shell, Brass Body, TRIAD 01 Series, TE - TRIAD 01 Series 5-1437720-6 Socket Contacts
MASTER:
T01 FEMALE PLUG CONNECTOR CRIMPV. 3-5 POS. T01 BUCHSENSTECKER CRIMPV. 3-5 POLIG
Powell:
Shielded Circular Subminiature Connectors TRIAD 01
Online Components:
T01-0540-S03-FEMALE PLUG CONNECTOR-CRIMP
Electro Sonic:
T01-0540-S03-FEMALE PLUG CONNECTOR-CRIMP
触点数 3
极性 Male
额定电流 3 A
易燃性等级 UL 94 V-2
针脚数 3
额定电流Max 3 A
工作温度Max 80 ℃
工作温度Min -40 ℃
额定电压Max 60 VAC
额定电压 60 VAC
封装 -
长度 38 mm
封装 -
外壳颜色 Silver
工作温度 -40℃ ~ 80℃
产品生命周期 Active
包装方式 Bulk
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ELV标准 Compliant
REACH SVHC版本 2015/06/15
ECCN代码 EAR99
HTS代码 8536698000
