WEIDMULLER 1607520000 针座, 法兰安装, 3.5MM, 4路
The is a 4-pole orange Terminal Block Header with THT solder connection and 180° outgoing elbow. The SL 3.50/04/180F 3.2SN OR BX header has tinned CuSn contact with PBT insulation. It is pin header for wave soldering in 3.50mm pitch and plugging direction is straight to the PCB with screw flange housing variant.
触点数 4
极性 Male
触点电镀 Tin
额定电流 10 A
绝缘电阻 1.00 MΩ
排数 1
易燃性等级 UL 94 V-0
针脚数 4
安装角度 180 °
额定电压 300 V
安装方式 Through Hole
引脚间距 3.50 mm
长度 29.8 mm
宽度 7.50 mm
高度 11.1 mm
引脚间距 3.50 mm
外壳颜色 Orange
颜色 Orange
触点材质 Copper Alloy
工作温度 -50℃ ~ 100℃
外壳材质 Plastic
产品生命周期 Active
包装方式 Bulk
制造应用 工业, Industrial
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
