14311016102000

10 位置 单排 12-30 AWG Har-Flexicon 5.00 FPH-10 B100 GN 连接器

har-flexicon® - The connection of PCBs shows a clear trend towards the miniaturization and reflow-soldering connection technology. This requires innovative answers regarding size, utilization, flexibility, and handling of the components.

The har-flexicon® product family has been designed for the toolless connection of single wires and the SMT/SMC-reflow-soldering process. har-flexicon® ensures an efficient processing for both the device production and the device installation.

得捷:
TERM BLOCK PLUG 10POS STR 5MM

贸泽:
可插拔接线端子 10P 300V 12A 5 mm pitch spring, plug

艾睿:
This spring cage terminal block 14311016102000 PCB terminal block manufactured from Harting will connect wires together. This F connector has 10 F contacts. This is a 1-row connector. It has a right angle body orientation. It has a female type gender. Its pitch is 5 mm. It has a maximum voltage rating of 300 V. 14311016102000 is housed in polyamide/polyphthalamide. This device has a maximum current rating of 12 A. This product is 14.9 mm tall. This quick disconnect terminal has an operating temperature of -40 to 110 °C. Its wire is 12-30 AWG.

Allied Electronics:
Conn; Terminal Block; 5.00mm Pitch; FemaleCon; Horizl; 10 Pin; B100; Green; harflexicon

Verical:
Conn Spring Cage Terminal Block F 10 POS 5mm RA Cable Mount 12A har-flexicon® Bulk

Newark:
# HARTING  14311016102000  Pluggable Terminal Block, 5 mm, 10 Positions, 30 AWG, 12 AWG, 2.5 mm², Push In
