14310816402000

8 位置 单排 12-30 AWG Har-Flexicon 5.00 FSH-8 B100 GN 连接器

har-flexicon® - The connection of PCBs shows a clear trend towards the miniaturization and reflow-soldering connection technology. This requires innovative answers regarding size, utilization, flexibility, and handling of the components.

The har-flexicon® product family has been designed for the toolless connection of single wires and the SMT/SMC-reflow-soldering process. har-flexicon® ensures an efficient processing for both the device production and the device installation.

得捷:
TERM BLOCK PLUG 8POS 90DEG 5MM

艾睿:
Joining multiple circuits is easy with this 14310816402000 PCB terminal block from Harting. This F connector has 8 F contacts. This is a 1-row connector. It has a right angle body orientation. It has a female type gender. Its pitch is 5 mm. It has a maximum voltage rating of 300 V. 14310816402000 is housed in polyamide/polyphthalamide. This device has a maximum current rating of 15 A. Its wire is 12-30 AWG. This product is 40 mm long, 10 mm tall and 8.2 mm deep. It uses the screw termination method. This quick disconnect terminal has an operating temperature of -40 to 110 °C.

Allied Electronics:
Conn; Terminal Block; 5.00mm Pitch; FemaleCon; Horizl; 8 Pin; B100; Green; har-flexicon

Verical:
Conn Terminal Block F 8 POS 5mm Screw RA Cable Mount 15A har-flexicon® Bulk

Newark:
# HARTING  14310816402000  Pluggable Terminal Block, 5 mm, 8 Positions, 30 AWG, 12 AWG, 2.5 mm², Screw
