1690220000

WEIDMULLER  1690220000  插拔式接线端子, 5 路, 300 V, 10 A, 3.5 mm, 26 AWG, 14 AWG

The is a 5-pole orange female PCB Plug-in Connector with tension clamping connection. The BL 3.50/05/180 SN OR BX connector has tinned Cu-leg contact with 4 to 8µm Sn hot-dip tinned layer structure of plug contact and a PBT insulator. The female connector is suitable for connecting cables in 3.5 pitch. The female plug provides space for labelling and can be coded.

.

Safe from finger touch

.

>=10⁸R Insulation resistance

.

5mR Volume resistance

.

DIN 5264-A Screwdriver blade standard

.

IP20 Protection

.

UL94V-0 Flammability

.

-50 to 100°C Operating temperature range
