14310416402000

4 位置 单排 12-30 AWG Har-Flexicon 5.00 FSH-4 B150 GN 连接器

4 针位端子块 插头，母插口 0.197"（5.00mm） 90° 自由悬挂

得捷:
TERM BLOCK PLUG 4POS 90DEG 5MM

e络盟:
端子块, 插入式, 4路, 30-12AW

艾睿:
Know that you will have strong connections between circuits when you use Harting&s;s 14310416402000 PCB terminal block. This F connector has 4 F contacts. It has a right angle body orientation. It has a female type gender. It has a maximum voltage rating of 300 V. This is a 1-row connector. Its pitch is 5 mm. This device has a maximum current rating of 15 A. 14310416402000 is housed in polyamide/polyphthalamide. It uses the screw termination method. This quick disconnect terminal has an operating temperature of -40 to 110 °C. Its wire is 12-30 AWG. This product is 20 mm long, 10 mm tall and 8.2 mm deep.

Allied Electronics:
Conn; Terminal Block; 5.00mm Pitch; FemaleCon; Horizl; 4 Pin; B150; Green; har-flexicon

富昌:
4 位置 单排 12-30 AWG Har-Flexicon 5.00 FSH-4 B150 GN 连接器

Verical:
Conn Terminal Block F 4 POS 5mm Screw RA Cable Mount 15A har-flexicon® Bulk

Newark:
# HARTING  14310416402000  Pluggable Terminal Block, 5 mm, 4 Positions, 30 AWG, 12 AWG, 2.5 mm², Screw
