1-282834-0

TE CONNECTIVITY / BUCHANAN  1-282834-0  接线端子块, PCB安装, 90, 10路

TERMI-BLOK PCB MOUNT, 90 10P.

Product Highlights

Connector

Connector Type = Wire Receptacle

Housing Color = Green

Not Side Stackable

Without Screw Flange

得捷:
TERM BLK 10P SIDE ENT 2.54MM PCB

立创商城:
1-282834-0

e络盟:
端子块, 线至板, 10路, 直角型, 16AWG

艾睿:
Join your electrical circuits and ensure strong connections with this eurostyle block 1-282834-0 PCB terminal block from TE Connectivity. This is a 1-row connector. Its pitch is 2.54 mm. It has a straight body orientation. It has a maximum voltage rating of 150 VAC. 1-282834-0 is housed in polyamide 6/6. This device has a maximum current rating of 10 A/contact. It uses the solder termination method. This product is 25.86 mm long, 10 mm tall and 6.5 mm deep. This quick disconnect terminal has an operating temperature of -40 to 105 °C.

安富利:
Conn Terminal Block 10 POS 2.54mm Solder ST Thru-Hole 10A/Contact

Chip1Stop:
Conn Terminal Block 10 POS 2.54mm Solder ST Thru-Hole 10A/Contact

Verical:
Conn Eurostyle Block 10 POS 2.54mm Solder ST Thru-Hole 10A/Contact Box

MASTER:
TERMINAL BLOCK PCB MOUNT SIDE WIRE ENTRY STACKING 2.54mm PITCH

Powell:
Terminal Block Connectors

Online Components:
TERMI-BLOK PCB MOUNT, 90 10P.

Electro Sonic:
TERMI-BLOK PCB MOUNT, 90 10P.
