1040810000

WEIDMULLER 1040810000 Terminal Block, Header, 3.81mm, 6 Ways, 10A, 300V, Through Hole Right Angle

The is a 6-pole black Terminal Block Header with THT solder connection and 90° outgoing elbow. The SCDN 3.81/06/90G 3.2SN BK BX header has tinned Cu-Leg contact with GF-polyamide insulation. It is 3.81mm-pitch plug-in connector compatible with the layouts of standard connectors and offer space for labelling and coding.

.

Two compact interfaces are used with the flat BCF 3.81 push-in socket block

.

Connections on a single level, allowing access that is flush over the front board

.

Space for labelling and coding

.

Safe from finger touch

.

IP20 Protection

.

UL94V-0 Flammability rating

.

-50 to 120°C Operating temperature
