1862810000

WEIDMULLER  1862810000  针座, 3.81MM, 直角型, 2路

The is a 2-pole black Terminal Block Header with THT/THR solder connection and 90° outgoing elbow. The SC-SMT 3.81/02/90G 3.2SN BK RL header has tinned Cu-Leg contact with LCP GF insulation. It is high-temperature-resistant pin header SC-SMT 90G in 3.81mm pitch compatible with the layouts of standard connectors and offer space for labelling and coding with plugging direction parallel to PCB and closed housing variant.

.

Safe from finger touch

.

IP20 Protection

.

UL94V-0 Flammability rating

.

-50 to 120°C Operating temperature range
