1948070000

WEIDMULLER  1948070000  插拔式接线端子, 9 路, 400 V, 15.5 A, 5.08 mm, 26 AWG, 12 AWG

The is a 9-pole orange female PCB Plug-in Connector with clamping yoke connection. The BLZP 5.08HC/09/90 SN OR BX connector has tinned Cu-leg contact with a 4 to 8µm Sn hot-dip tinned layer structure of plug contact and a PBT insulator. The female plug is suitable for connecting wires with a right-angle 90° outlet direction. The female connector provides space for labelling and can be coded. It is fastened by means of a flange or release latch. It also provides an integrated plus/minus screw, protection against faulty insertion of the wire and it is delivered with open clamping yokes.

.

Safe from finger touch

.

>=10⁸R Insulation resistance

.

5mR Volume resistance

.

0.4 to 0.5Nm Tightening torque

.

DIN 5264, ISO 8764/2-PH, ISO 8764/2-PZ Standard screwdriver blade

.

UL94V-0 Flammability

.

-50 to 100°C Operating temperature range
