D2n 系列 3 A 双刀双掷 24 VDC 非闭锁 通孔 信号 继电器
V23105A5405A201
Product Highlights
V23105 / D2n Relay Series
DC Actuating System
Input Voltage = 24 VDC
Contact Arrangement = 2 Form C, DPDT, 2 C/O
Contact Current Rating = 3 Amps.
得捷:
V23105A5405A201
e络盟:
信号继电器, 24 VDC, DPDT, 3 A, D2n/V23105系列, 通孔安装, 非闭锁
艾睿:
Signal Relay 24VDC 3A DPDT 20.2mm 10mm 11mm THT
Jameco:
Electromechanical Relay Double Pole Double Throw 3A 24 Volt 1.44Kohm Through Hole
安富利:
Electromechanical Relay DPDT 3A 24VDC 1.44KOhm Through Hole
Chip1Stop:
Electromechanical Relay 24VDC 1.44KOhm 3A DPDT 20.2x10x11mm THT Signal Relay
TME:
Series: D2N
Verical:
Electromechanical Relay 24VDC 1.44KOhm 3A DPDT 20.2x10x11mm THT Signal Relay
MASTER:
Telecom Relay DPDT 2 Form C 24VDC Coil Through Hole
Powell:
2G COM Relay
Online Components:
V23105A5405A201
Electro Sonic:
Telecom Relay DPDT 2 Form C 24VDC Coil Through Hole
触点电镀 Gold
额定电压DC 220 V
额定电压AC 250 V
额定电流 3.00 A
输入电压DC 24.0 V
触点类型 DPDT
功耗 400 mW
触点额定电流 3 A
线圈电压 24 VDC
线圈电流 16.67 mA
线圈功率DC 400 mW
线圈电阻 1.44 KΩ
载流 3.00 A
额定电流Max 3 A
线圈电压DC 24 V
额定功率Max 60W, 125VA
开关电流Max 3 A
工作温度Max 85 ℃
工作温度Min -40 ℃
额定电压DC Max 220 V
额定电压AC Max 250 V
接触电阻Max <100 mΩ
安装方式 Through Hole
引脚数 8
封装 DIP
长度 20.3 mm
宽度 10.1 mm
高度 11 mm
封装 DIP
触点材质 Silver Nickel, Gold
工作温度 -25℃ ~ 75℃
产品生命周期 Active
包装方式 Tube
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ELV标准 Compliant
REACH SVHC标准 No SVHC
REACH SVHC版本 2014/06/16
ECCN代码 EAR99
HTS代码 8536490075
