DIP, Rotary DIP, SIP Switches and DIP Shunts - Standard
ADF1004=DIP SWT,FLUSH,THRU/HL
艾睿:
Thanks to the 1-1825002-7 dual in-line package switch from TE Connectivity, you can ensure that there is some type of current flow control within your printed circuit. It has a SPST configuration. This device has a maximum current rating of 0.1 A @ 24VDC. This DIP switch has an operating temperature range of -30 °C to 85 °C. The 1-1825002-7 DIP switch has a PC pin termination style. This product&s;s terminal pitch is 2.54 mm. This product is 27.4 mm long, 4.81 mm tall and 8.35 mm deep. The maximum DC voltage rating is 24 VDC.
安富利:
Switch DIP OFF ON SPST 10 Flush Slide 0.1A 24VDC PC Pins 2.54mm Thru-Hole Tube
Chip1Stop:
Switch DIP OFF ON SPST 10 Flush Slide 0.1A 24VDC PC Pins 2.54mm Thru-Hole Tube
Verical:
Switch DIP OFF ON SPST 10 Flush Slide 0.1A 24VDC PC Pins 2.54mm Thru-Hole Tube
MASTER:
DIP SWITCH, ADF THRU HOLE
Powell:
DIP, Rotary DIP, SIP Switches and DIP Shunts - Standard
Online Components:
ADF1004=DIP SWT,FLUSH,THRU/HL
Electro Sonic:
ADF1004=DIP SWT,FLUSH,THRU/HL
触点电镀 Gold, Gold over Nickel, Gold Flash
额定电压DC 24 V
额定电流 100 mA
触点类型 SPST
易燃性等级 UL 94 V-0
针脚数 10
额定电流Max 0.1A @24VDC
工作温度Max 85 ℃
工作温度Min -30 ℃
额定电压 24 VDC
额定电压DC Max 24 V
接触电阻Max 50 mΩ
安装方式 Through Hole
长度 27.38 mm
宽度 8.35 mm
高度 4.81 mm
外壳颜色 Black
触点材质 Copper Alloy
工作温度 -30℃ ~ 85℃
产品生命周期 Active
包装方式 Tube
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ELV标准 Compliant
ECCN代码 EAR99
HTS代码 8536509032
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
1-1825002-7 TE Connectivity 泰科 | 当前型号 | 当前型号 |
ADF10 泰科 | 类似代替 | 1-1825002-7和ADF10的区别 |
A6T-0104 欧姆龙 | 功能相似 | 1-1825002-7和A6T-0104的区别 |
SDA10H0B C&K Components | 功能相似 | 1-1825002-7和SDA10H0B的区别 |
