104128-1

Connector Ejector Header 10Position 2.54mm Solder Straight Through Hole

针座 通孔 10 位置 0.100"（2.54mm）

得捷:
CONN HEADER VERT 10POS 2.54MM

欧时:
10P HDR W/LATCH LOW PROFILE

艾睿:
Easily mount this ejector 104128-1 header connector from TE Connectivity onto your PCB project to support a variety of physical configuration options. This HDR connector&s;s 10 contacts that are made out of phosphor bronze and plated with gold over palladium nickel over nickel|gold over nickel. It has a header type gender. It has a straight body orientation. This is a 2-row connector. Its pitch is 2.54 mm. This device has a maximum current rating of 1 A/contact. The component will be shipped in tray format. 104128-1 is housed in black nylon. This connector has an operating temperature of -65 to 105 °C. It uses the solder termination method. This product is 23.29 mm tall.

Jameco:
Connector Ejector Header 10 Position 2.54mm Solder Straight Through Hole

安富利:
Conn Ejector Header HDR 10 POS 2.54mm Solder ST Thru-Hole

Verical:
Conn Ejector Header HDR 10 POS 2.54mm Solder ST Thru-Hole Automotive Tray

Newark:
# AMP - TE CONNECTIVITY  104128-1  010 LOPRO HDR SP 30DP LATCH

MASTER:
HEADER ASSY, LOW PROFILE, AMP-LATCH

Powell:
Pin and Pinless Headers AMP-LATCH

Online Components:
010 LOPRO HDR SP 30DP LATCH

Electro Sonic:
010 LOPRO HDR SP 30DP LATCH
