1911884

Phoenix Contact COMBICON MSTB 2,5 HC 系列 5.0mm 插入式端子块连接器COMBICON MSTB 2,5 HC 系列 5.0mm 插入式电缆安装端子块连接器，带母插座，具有螺钉连接且高电流载流量为 16A。 这些 COMBICON MSTB 2,5 HC 系列 5.0mm 自由悬挂高电流端子块插头应仅与 MSTB 2,5 HC 端子块管座一起使用。 有关螺丝刀，请参见库存号 390-9641### Phoenix Contact COMBICON 5.0mm 两件式端子块

Contact COMBICON MSTB 2,5 HC 系列 5.0mm 插入式端子块

COMBICON MSTB 2,5 HC 系列 5.0mm 插入式电缆安装端子块连接器，带母插座，具有螺钉连接且高电流载流量为 16A。 这些 COMBICON MSTB 2,5 HC 系列 5.0mm 自由悬挂高电流端子块插头应仅与 MSTB 2,5 HC 端子块管座一起使用。

有关螺丝刀，请参见库存号 390-9641

### Phoenix Contact COMBICON 5.0mm 两件式端子块

欧时:
MSTB 2,5 HC /5-ST 5way 5mm

得捷:
TERM BLOCK PLUG 5POS STR 5MM

贸泽:
Pluggable Terminal Blocks 5 Pos 5mm pitch Plug 24-12 AWG Screw

艾睿:
Connecting one or more circuits together, this 1911884 PCB terminal block from Phoenix Contact is a must-have! This F connector has 5 contacts that are plated with tin. It has a female type gender. This is a 1-row connector. It has a maximum voltage rating of 320 V. Its pitch is 5 mm. It has a right angle body orientation. This device has a maximum current rating of 16 A. 1911884 is housed in polyamide. Its wire is 12-24 AWG. It uses the screw termination method. This product is 25 mm long, 15 mm tall and 18.2 mm deep.

Allied Electronics:
Conn; Term Blk; PCB; Plug; Screw; 5; 5 mm; 24-12 AWG; Green; 16 A; 250 V; M 3

Verical:
COMBICON HC plugs, 5.0 mm pitch, color: Green, no. of positions 7,dimension a 30 mm

MASTER:
PCB connector - nominal current: 16 A - rated voltage III/2: 320 V - nominal cross section: 2.5 mm² - number of positions: 5 - pitch: 5 mm - connection method: Screw connection with tension sleeve - color: green - contact surface: Tin

Online Components:
Conn Terminal Block F 5 POS 5mm Screw RA Cable Mount 16A

Electro Sonic:
PCB connector - nominal current: 16 A - rated voltage III/2: 320 V - nominal cross section: 2.5 mm² - ...
