1-1954289-1

Board to Board### TE Connectivity Hermaphroditic 刀片和插座连接器Hermaphoroditic 刀片和插座连接器是 SMT 连接器，适用于直插式板对板应用。 应用包括：LED 照明控制、LED 照明带、立体发光字连接器可单独使用 单部件库存，每个置于印刷电路板上 连接器可水平、垂直结合和解开 连接器可进行 90° 到 180° 铰接 薄型扁平表面与 SMT 和回流处理兼容 圆角可减少遮蔽 备用 SMT 垫 焊接垫足迹，与 Tyco Electronics SMT Poke-In LED 连接器兼容

板对板

得捷:
CONN SSL RCPT & BLADE 2POS 4MM

欧时:
### Board to Board### TE Connectivity Hermaphroditic 刀片和插座连接器Hermaphoroditic 刀片和插座连接器是 SMT 连接器，适用于直插式板对板应用。 应用包括：LED 照明控制、LED 照明带、立体发光字连接器可单独使用 单部件库存，每个置于印刷电路板上 连接器可水平、垂直结合和解开 连接器可进行 90° 到 180° 铰接 薄型扁平表面与 SMT 和回流处理兼容 圆角可减少遮蔽 备用 SMT 垫 焊接垫足迹，与 Tyco Electronics SMT Poke-In LED 连接器兼容

艾睿:
Protect your printed circuit boards from accidental damages with TE Connectivity&s;s board to board 1-1954289-1 header connector. This M connector&s;s 2 contacts that are made out of copper alloy and plated with tin over nickel. It has a right angle body orientation. This is a 1-row connector. Its pitch is 4 mm. It has a male type gender. It has a maximum voltage rating of 125 VDC|125VAC. This device has a maximum current rating of 6 A/contact. In order to guarantee safe delivery and allow for quick mounting of this component after delivery, it will be enclosed in tape and reel packaging during shipment. This product is 7.9 mm long, 3.9 mm tall and 19.75 mm deep. 1-1954289-1 is housed in black liquid crystal polymer. It uses the solder termination method. This connector has an operating temperature of -40 to 105 °C.

Allied Electronics:
Connector, Blade and Receptacle, Hermaphroditic, Lighting, 2 Position, Black

安富利:
Conn Board to Board M 2 POS 4mm Solder RA SMD T/R

Chip1Stop:
Conn Board to Board M 2 POS 4mm Solder RA SMD T/R

Verical:
Wire to Board Connector M 2 POS 4mm Solder RA SMD T/R

Newark:
# TE CONNECTIVITY  1-1954289-1  Board-To-Board Connector, 4 mm, 2 Contacts, Receptacle, Surface Mount, 1 Rows

Powell:
LED Interconnects

Online Components:
Connector,Blade & Recpt 2 Pos

Electro Sonic:
Connector,Blade & Recpt 2 Pos
