1469025-1

2.5 mm 40 位置 针座 压接 通孔 硬公制 连接器

** Z-PACK™ HM-Zd Headers and Connector Assemblies**

Z-PACK™ HM-Zd headers and connector assemblies with a 2.50mm centerline. These Z-PACK™ HM-Zd Pin headers and receptacle connector assemblies are press fit PCB through hole mounting and have polyester GF housings.

得捷:
CONN HEADER HIGH SPEED 60POS PCB

立创商城:
1469025-1

艾睿:
TE Connectivity&s;s high speed 1469025-1 backplane connector is a great component to use when you want to relay data bits via parallel electrical lines. This HDR connector&s;s 40 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a maximum voltage rating of 250 VAC. Its pitch is 2.5 mm. It has a header type gender. It has a straight body orientation. This is a 4-row connector. This device has a maximum current rating of 7 A/contact. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. It uses the press fit termination method. This product is 24.9 mm long, 13.4 mm tall and 15.43 mm deep. 1469025-1 is housed in polyester. This backplane connector has an operating temperature of -65 to 105 °C.

Allied Electronics:
HEADER; HM-ZD; 40 POS; 10 COLUMN; ACTION PIN POST; 2.50 MM; PCB

安富利:
Conn High Speed HDR 40 POS 2.5mm Press Fit ST Thru-Hole

Verical:
Conn High Speed HDR 40 POS 2.5mm Press Fit ST Thru-Hole Tube

Newark:
# AMP - TE CONNECTIVITY  1469025-1  HM-ZD 2PR HDR 40P 2.5MM New

MASTER:
HEADER ASSEMBLY, 2 PAIR, 2.5mm TAIL, 25mm, HMZd

Powell:
Z-PACK HM-Zd Connectors, Cable Assemblies and Accessories

Online Components:
HM-ZD 2PR HDR 40P 2.5MM

Win Source:
CONN HEADER 40POS 2ROW VERT

Electro Sonic:
HM-ZD 2PR HDR 40P 2.5MM
