4 位置 10.16 mm 间距 12-30 AWG 直角 欧式 接线端子
4 针位端子块 插头,母插口 0.400"(10.16mm) - 180° 自由悬挂
得捷:
TERM BLOCK PLUG 4POS STR 10.16MM
艾睿:
Ideal for testing purposes this 1-282809-5 PCB terminal block manufactured from TE Connectivity will exceed your needs. This PL connector&s;s 4 contacts that are made out of phosphor bronze/brass and plated with tin/nickel. This is a 1-row connector. Its pitch is 10.16 mm. It has a plug type gender. It has a right angle body orientation. 1-282809-5 is housed in polyamide 6/6. Its wire is 12-30 AWG. It uses the screw termination method. This product is 35.56 mm long, 15.5 mm tall and 18.4 mm deep.
Chip1Stop:
Conn Terminal Block PL 4 POS 10.16mm Screw RA Cable Mount
Verical:
Conn Terminal Block F 4 POS 10.16mm Screw RA Cable Mount Package
MASTER:
Conn Terminal Block F 4 POS 10.16mm Screw RA Cable Mount Package
Online Components:
TERMI-BLOK PLUG STACKING 4P, M
触点数 4
线规 12AWG ~ 30AWG
排数 1
电路数 4
易燃性等级 UL 94 V-0
针脚数 4
工作温度Max 105 ℃
工作温度Min -40 ℃
额定电压Max 600 VAC
工作电压Max 600 VAC
长度 35.56 mm
宽度 18.4 mm
高度 15.5 mm
外壳颜色 Black
颜色 Black
触点材质 Phosphor Bronze
工作温度 -40℃ ~ 110℃
外壳材质 Nylon 6/6
产品生命周期 Active
包装方式 Box
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ELV标准 Compliant
ECCN代码 EAR99
HTS代码 8538908080
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
1-282809-5 TE Connectivity 泰科 | 当前型号 | 当前型号 |
1-1776770-4 泰科 | 功能相似 | 1-282809-5和1-1776770-4的区别 |
