1863084

Phoenix Contact MINI COMBICON MCVW 系列 3.5mm 节距 10 路 母 绿色 插头 1863084, 螺钉端接

Conn Terminal Block F 10 POS 3.5mm Screw ST Panel Mount 8A

得捷:
TERM BLOCK PLUG 10POS 3.5MM

欧时:
Phoenix Contact 1863084 MINI COMBICON MCVW 系列 3.5mm 节距 10 路 母 插头, 螺钉端接 绿色

贸泽:
可插拔接线端子 10 Pos 3.5mm pitch Plug 28-16 AWG Screw

艾睿:
Create a bridge between two sides of a circuit by implementing this 1863084 PCB terminal block from Phoenix Contact. This F connector has 10 contacts that are plated with tin. Its pitch is 3.5 mm. This is a 1-row connector. It has a maximum voltage rating of 160 V. It has a straight body orientation. It has a female type gender. This device has a maximum current rating of 8 A. 1863084 is housed in polyamide. It uses the screw termination method. This product is 45.4 mm long, 19.1 mm tall and 10.4 mm deep. Its wire is 16-28 AWG.

Verical:
Conn Terminal Block F 10 POS 3.5mm Screw ST Panel Mount 8A

Online Components:
Conn Terminal Block F 10 POS 3.5mm Screw ST Panel Mount 8A

Electro Sonic:
PCB connector - nominal current: 8 A - rated voltage III/2: 160 V - nominal cross section: 1.5 mm² - ...
