Phoenix Contact COMBICON PT 3.5mm 印刷电路板端子块专业系列水平或垂直 Phoenix Contact 印刷电路板端子块来自 PT 系列。3.5mm 节距 螺钉连接 提供各种位置 26-14 线规范围 水平或垂直安装选项 ### Phoenix Contact COMBICON 3.5mm 印刷电路板端子块

Contact COMBICON PT 3.5mm 印刷电路板端子块

专业系列水平或垂直 Phoenix Contact 印刷电路板端子块来自 PT 系列。

###

**特点和优势**

• 3.5 mm 节距

• 螺钉连接

• 提供各种位置

• 26-14 线规范围

• 水平或垂直安装选项

### Phoenix Contact 3.5mm 印刷电路板端子块

得捷:
TERM BLOCK PLUG 3POS 3.5MM

欧时:
Phoenix Contact COMBICON COMPACT PT 系列 1984028 3 路 无熔丝端子块, 电缆安装, 螺钉拧紧端接

艾睿:
Create a bridge between two sides of a circuit by implementing this 1984028 PCB terminal block from Phoenix Contact. This F connector has 3 contacts that are plated with tin. It has a maximum voltage rating of 200 V. Its pitch is 3.5 mm. This is a 1-row connector. It has a right angle/straight body orientation. It has a female type gender. 1984028 is housed in polyamide. This device has a maximum current rating of 8 A. Its wire is 16-26 AWG. This product is 10.5 mm long, 11.1 mm tall and 14.6 mm deep. It uses the screw termination method.

Allied Electronics:
Conn; Term Blk; PCB; Plug; Screw; 3; 3.5 mm; 26-16 AWG; 8 A; 300 V; M2; PA

Verical:
Conn Terminal Block F 3 POS 3.5mm Screw Straight/Right Angle Cable Mount 8A

MASTER:
PCB connector - nominal current: 8 A - rated voltage III/2: 200 V - nominal cross section: 1.5 mm² - number of positions: 3 - pitch: 3.5 mm - connection method: Screw connection with wire protector - color: green - contact surface: Tin

Online Components:
Conn Terminal Block F 3 POS 3.5mm Screw Right Angle/Straight Cable Mount 8A

Electro Sonic:
PCB connector - nominal current: 8 A - rated voltage III/2: 200 V - nominal cross section: 1.5 mm² - ...
