1766783

Phoenix Contact CLASSIC COMBICON GMSTBVA 7.62mm 系列印刷电路板端子块管座专业系列的 7.62 mm 节距 GMSTBVA 系列通孔管座7.62 mm 节距 提供各种位置 通孔安装 线对板 ### Phoenix Contact COMBICON 7.62mm 两件式端子块### 认可UL94V-0

Contact CLASSIC COMBICON GMSTBV 和 GMSTBVA 7.62mm 系列印刷电路板端子块管座

专业系列 7.62 mm 节距 GMSTBVA 和 GMSTBV 系列通孔管座

7.62 mm 节距

提供各种位置

通孔安装

线对板

得捷:
TERM BLOCK HDR 3POS VERT 7.62MM

欧时:
Phoenix Contact PCB 接线端子块 COMBICON GMSTBVA 系列 3路 7.62mm节距 1排 直向 1766783, 焊接端接, 12A

立创商城:
7.62mm

艾睿:
Use this shrouded 1766783 connector from Phoenix Contact when board-to-board interconnects is required. This HDR connector has 3 contacts that are plated with tin. This is a 1-row connector. It has a header type gender. It has a maximum voltage rating of 400 V. It has a straight body orientation. Its pitch is 7.62 mm. This device has a maximum current rating of 12 A. This product is 22.86 mm long, 12 mm tall and 8.6 mm deep. It uses the solder termination method. 1766783 is housed in green polyamide.

Allied Electronics:
GMSTBVA Series, 7.62mm Pitch 3 Way 1 RowStraight PCB Header, Solder Term, 12A

Verical:
Conn Shrouded Header 4 Sides HDR 3 POS 7.62mm Solder ST Thru-Hole

MASTER:
PCB headers - nominal current: 12 A - rated voltage III/2: 630 V - nominal cross section: 2.5 mm² - number of positions: 3 - pitch: 7.62 mm - color: green - contact surface: Tin - mounting: Wave soldering - pin layout: Linear pinning - solder pin [P]: 3

Online Components:
Conn Shrouded Header HDR 3 POS 7.62mm Solder ST Thru-Hole

Electro Sonic:
PCB headers - nominal current: 12 A - rated voltage III/2: 630 V - nominal cross section: 2.5 mm² - ...
