1437540-3

32Positions 2.54mm Centerline Through Hole DIP Socket

Say goodbye to connector sockets never working by using this dip socket connector socket developed by . This SKT connector"s 32 contacts that are made out of beryllium copper and plated with gold over nickel. Its pitch is 2.54 mm. It has a straight body orientation. It has a socket type gender. This is a 2-row connector. 1437540-3 is housed in polyester. This device has a maximum current rating of 3 A/contact. This product is 40.64 mm long, 4.57 mm tall and 17.78 mm deep. This connector socket has an operating temperature of -55 to 105 °C. It is insulated with polyester. It uses the solder termination method.
