1-5103310-0

AMP FROM TE CONNECTIVITY  1-5103310-0  线至板连接器, 针座, 50路, 2.54MM

A/L LOW PRO HDR 50P RA BLACK

Product Highlights

Preloaded

Connector Style = Header - Pin

Header Type = Pin Header

AMP-LATCH Product Line

Low Profile

得捷:
CONN HEADER R/A 50POS 2.54MM

欧时:
A/L LOW PRO HDR 50P RA BLACK

立创商城:
1-5103310-0

e络盟:
线至板连接器, 针座, 50路, 2.54MM

艾睿:
Reduce safety concerns with this shrouded 1-5103310-0 header connector from TE Connectivity which will reduce the possibility of accidentally shorting pins when a printed circuit board is being used. This HDR connector&s;s 50 contacts that are made out of brass and plated with gold over palladium nickel over nickel|gold over nickel. This is a 2-row connector. It has a right angle body orientation. Its pitch is 2.54 mm. It has a header type gender. This device has a maximum current rating of 1 A/contact. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. This connector has an operating temperature of -65 to 105 °C. This product is 71.12 mm long, 9.14 mm tall and 12.31 mm deep. 1-5103310-0 is housed in black polybutylene terephthalate|nylon. It uses the solder termination method.

Allied Electronics:
Header; Through Hole; Shrouded; Right Angle; Copper Alloy; Thermoplastic; 50

安富利:
Conn Shrouded Header HDR 50 POS 2.54mm Solder RA Thru-Hole

Chip1Stop:
Conn Shrouded Header HDR 50 POS 2.54mm Solder RA Thru-Hole Tube

Verical:
Conn Shrouded Header 4 Sides HDR 50 POS 2.54mm Solder RA Thru-Hole Tube

Newark:
Wire-To-Board Connector, 2.54 mm, 50 Contacts, Header, AMP-LATCH Series, Through Hole, 2 Rows

MASTER:
Wire-To-Board Connector - 2.54 mm - 50 Contacts - Header - AMP-LATCH Series - Through Hole - 2 Rows.

Powell:
Pin and Pinless Headers AMP-LATCH

Online Components:
A/L LOW PRO HDR 50P RA BLACK

Electro Sonic:
Wire-To-Board Connector - 2.54 mm - 50 Contacts - Header - AMP-LATCH Series - Through Hole - 2 Rows.
