8 位置 直角 4 mm 焊接 通孔 带垫片 针座 组件
AMPSEAL 印刷电路板管座，IP67 保护等级
AMPSEAL 汽车印刷电路板安装管座具有彩色键接、4mm 中心线和粘接到法兰的硅衬垫，防水可达到 IP67 等级。 这些 AMPSEAL 汽车印刷电路安装板管座提供垂直或直角安装。
### TE Connectivity AMPSEAL
AMPSEAL 以其坚固的可靠性（甚至在高温汽车和工业应用中）而著称。 这些重型连接器不仅防水，还因其接口和电线的 2 路密封而潜在水中。
得捷:
CONN HEADER R/A 8POS 4MM
欧时:
AMPSEAL 8 way right angle plug header
立创商城:
4mm 弯插
贸泽:
Automotive Connectors 8 POS RTANG HDR ASSY W/GSKT
e络盟:
车用连接器, AMPSEAL Series, 直角插头, 8 触点, 压接针, PBT聚对苯二甲酸乙二醇酯, 玻璃纤维主体, 黄铜
艾睿:
Protect your printed circuit boards from accidental damages with TE Connectivity&s;s wire to board 1-776280-1 header connector. This HDR connector&s;s 8 contacts that are made out of brass and plated with gold. Its pitch is 4 mm. It has a right angle body orientation. It has a header type gender. This is a 3-row connector. 1-776280-1 is housed in black polybutylene terephthalate. This product is 40.8 mm long, 32.1 mm tall and 37.9 mm deep. It uses the solder termination method.
Allied Electronics:
AMPSEAL 8 way right angle plug header
安富利:
Conn Wire to Board HDR 8 POS 4mm Solder RA Thru-Hole
Chip1Stop:
Conn Wire to Board HDR 8 POS 4mm Solder RA Thru-Hole
Verical:
Conn Wire to Board HDR 8 POS 2mm Solder RA Side Entry Thru-Hole Automotive
MASTER:
HEADER ASSEMBLY, 8 POSITION, RIGHT ANGLE, AMPSEAL
Online Components:
8 POS RTANG HDR ASSY W/GASKET
Electro Sonic:
8POS,PIN DIA 1.3,HDR ASSY,90DEG,SLDR,SLD
