1-776231-4

AMPSEAL 35 位置 通孔 三排 直 插针针座

针座 面板安装，通孔 35 位置 0.157"（4.00mm）

得捷:
CONN HEADER VERT 35POS 4MM

贸泽:
Automotive Connectors HEADER 35 POS VERT

艾睿:
Use the 1-776231-4 power connector from TE Connectivity to power up your circuit with the least amount of losses. This HDR connector&s;s 35 contacts that are made out of brass and plated with gold over nickel. It has a header type gender. It has a maximum voltage rating of 250 VAC. It has a straight body orientation. Its pitch is 4 mm. This connector has a single port. This device has a maximum current rating of 17 A/contact. 1-776231-4 is housed in polybutylene terephthalate. This power connector has a minimum operating temperature of -40 °C and a maximum of 125 °C. This product is 32.1 mm deep. Its 35 terminals use the solder termination method.

Allied Electronics:
AMPSEAL; HEADER ASSY, 35 POS VERTICAL

安富利:
Conn Power HDR 35 POS 4mm Solder ST Thru-Hole Loose Piece

Chip1Stop:
Conn Power HDR 35 POS 4mm Solder ST Thru-Hole 35 Terminal 1 Port

Verical:
HEADER ASSY,35 POS VERTICAL

Newark:
# AMP - TE CONNECTIVITY  1-776231-4  HEADER ASSY,35 POS VERTICAL New

MASTER:
ASSEMBLY, HEADER, 35 POSITION, VERTICAL, AMPSEAL WITH FLANGE SEAL

Online Components:
HEADER ASSY,35 POS VERTICAL

Electro Sonic:
HEADER ASSY,35 POS VERTICAL
