集管和线壳 09 MODII HDR SRST SHRD .100CL
09 MODII HDR SRST SHRD .100CL
Product Highlights
Header
Header Type = Shrouded
Number of Rows = Single
Number of Positions = 9
Mating Post Length = 6.10 mm
得捷:
CONN HEADER VERT 9POS 2.54MM
贸泽:
集管和线壳 09 MODII HDR SRST SHRD .100CL
富昌:
Connector Shrouded Header HDR 9 POS 2.54mm Solder ST Thru-Hole Gang of Tubes
MASTER:
09 MODII HDR SRST SHRD .100CL
Powell:
.100 inch AMPMODU Headers
Online Components:
09 MODII HDR SRST SHRD .100CL
Electro Sonic:
09 MODII HDR SRST SHRD .100CL
触点数 9
触点电镀 Tin Lead, Tin over Nickel
额定电流 3 A
绝缘电阻 5000 MΩ
排数 1
方向 Vertical
易燃性等级 UL 94 V-0
针脚数 9
额定电流Max 3A/触头
工作温度Max 105 ℃
工作温度Min -65 ℃
安装方式 Through Hole
外壳颜色 Black
颜色 Black
触点材质 Copper Alloy
工作温度 -65℃ ~ 105℃
外壳材质 Thermoplastic
产品生命周期 Superseded
包装方式 Tube
制造应用 -
RoHS标准 Non-Compliant
含铅标准 Contains Lead
ELV标准 Non-Compliant
ECCN代码 EAR99
HTS代码 8536694040
