178305-2

Dynamic D-3100 系列管座TE Connectivity Dynamic 系列的 D-3100 系列管座具有镀锡固定支脚，以提高稳定性。 D-3100 系列管座的印刷电路板焊接尾线为镀锡，触点插片为镀金。 这些 D-3100 系列管座的建议印刷电路板厚度为 1.0 至 1.6mm。### 注有关配接的 D-3100 系列外壳，请参见典型库存号 680-1571### TE Connectivity Dynamic 3000 系列### Tyco 动态 3000 系列

Dynamic D-3100 系列管座

Dynamic 系列的 D-3100 系列管座具有镀锡固定支脚，以提高稳定性。 D-3100 系列管座的印刷电路板焊接尾线为镀锡，触点插片为镀金。 这些 D-3100 系列管座的建议印刷电路板厚度为 1.0 至 1.6mm。

### 注

有关配接的 D-3100 系列外壳，请参见典型库存号 680-1571

### Tyco 动态 3000 系列

得捷:
CONN HEADER R/A 10POS 3.81MM

立创商城:
3.81mm 2x5P 弯插

欧时:
Header horiz 10 way 2 row TAB 3.81mm D-3

贸泽:
Headers & Wire Housings HDR 10 POS R/A 15 AU DUAL

e络盟:
线至板连接器, 3.81 mm, 10 触点, 针座, Dynamic D-3100D系列, 通孔安装, 2 排

艾睿:
Easily connect a power supply to a circuit with this 178305-2 power connector from TE Connectivity. This M connector&s;s 10 contacts that are made out of copper alloy and plated with gold over nickel. It has a male type gender. It has a right angle body orientation. Its pitch is 3.81 mm. It has a maximum voltage rating of 250 VAC. This connector has a single port. 178305-2 is housed in nylon. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. This power connector has a minimum operating temperature of -55 °C and a maximum of 105 °C. Its 10 terminals use the solder termination method. This product is 29.24 mm long, 15.93 mm tall and 25.91 mm deep.

Allied Electronics:
HEADER HORIZ 10 WAY 2 ROW

安富利:
Conn Power M 10 POS 3.81mm Solder RA Thru-Hole 10 Terminal 1 Port Tube

Chip1Stop:
Conn Power M 10 POS 3.81mm Solder RA Thru-Hole 10 Terminal 1 Port Tube

TME:
Socket; wire-board; male; D-3100D; 3.81mm; PIN:10; Pin layout:2x5

Verical:
Conn Power M 10 POS 3.81mm Solder RA Thru-Hole 10 Terminal 1 Port Box/Tube

Newark:
# AMP - TE CONNECTIVITY  178305-2  Wire-To-Board Connector, Dynamic D-3100D Series, Through Hole, Header, 10, 3.81 mm

MASTER:
10 POS DOUBLE ROW HORIZONTAL HDR ASS"Y FOR DYNAMIC 3100

Powell:
Dynamic Series Connectors

Online Components:
10-P POST HDR HORZ D-3100D .38

Electro Sonic:
DYNAMIC D3100D HDR H 10P ASSY AU038

Win Source:
CONN HEADER R/A 10POS 3.81MM / Connector Header Through Hole, Right Angle 10 position 0.150" 3.81mm
