Phoenix Contact MINI COMBICON TFMC 系列 3.5mm 节距 10 路 母 绿色 插头 1772692, 弹簧笼端接
Conn Terminal Block F 20 POS 3.5mm ST Cable Mount 8A
得捷:
TERM BLOCK PLUG 10POS STR 3.5MM
欧时:
Phoenix Contact MINI COMBICON TFMC 系列 3.5mm 节距 10 路 母 绿色 插头 1772692, 弹簧笼端接
艾睿:
Need to ensure strong connections between circuits? This 1772692 PCB terminal block from Phoenix Contact will do just that! This F connector has 20 F contacts. Its pitch is 3.5 mm. It has a straight body orientation. It has a maximum voltage rating of 160 V. This is a 2-row connector. It has a female type gender. This device has a maximum current rating of 8 A. 1772692 is housed in polyamide. Its wire is 16-24 AWG. This product is 35.8 mm long, 15.7 mm tall and 22.9 mm deep.
Verical:
Conn PC Terminal Block F 20 POS 3.5mm ST Cable Mount 8A
MASTER:
PCB connector - nominal current: 8 A - rated voltage III/2: 160 V - nominal cross section: 1.5 mm² - number of positions: 10 - pitch: 3.5 mm - connection method: Push-in spring connection - color: green - contact surface: Tin
Online Components:
Conn Terminal Block F 20 POS 3.5mm ST Cable Mount 8A
Electro Sonic:
PCB connector - nominal current: 8 A - rated voltage III/2: 160 V - nominal cross section: 1.5 mm² - ...
