1955853

Phoenix Contact PCB 接线端子块 COMBICON CCVA 系列 2路 5.08mm节距 1955853, 焊接端接, 12A

Conn Shrouded Header HDR 2 POS 5.08mm Solder ST Thru-Hole

得捷:
TERM BLOCK HDR 2POS VERT 5.08MM

欧时:
Phoenix Contact PCB 接线端子块 COMBICON CCVA 系列 2路 5.08mm节距 1955853, 焊接端接, 12A

贸泽:
可插拔接线端子 2 Pos 5.08mm pitch Through Hole Header

艾睿:
Support physical configuration options for jumper posts by mounting this shrouded 1955853 header connector from Phoenix Contact. This HDR connector has 2 contacts that are plated with tin. This is a 1-row connector. Its pitch is 5.08 mm. It has a straight body orientation. It has a header type gender. It has a maximum voltage rating of 320 V. This device has a maximum current rating of 12 A. 1955853 is housed in black liquid crystal polymer. This product is 12.96 mm long, 12 mm tall and 8.6 mm deep. It uses the solder termination method.

Verical:
Conn Shrouded Header HDR 2 POS 5.08mm Solder ST Thru-Hole

MASTER:
PCB headers - nominal current: 12 A - rated voltage III/2: 320 V - nominal cross section: 2.5 mm² - number of positions: 2 - pitch: 5.08 mm - color: black - contact surface: Tin - mounting: THR soldering - pin layout: Linear pinning - solder pin [P]: 2.

Online Components:
Conn Shrouded Header HDR 2 POS 5.08mm Solder ST Thru-Hole

Electro Sonic:
PCB headers - nominal current: 12 A - rated voltage III/2: 320 V - nominal cross section: 2.5 mm² - ...
