1859551

Phoenix Contact PCB 接线端子块 COMBICON EMSTBVA 系列 6路 5.08mm节距 1859551, 按式端接, 12A

Conn Shrouded Header HDR 6 POS 5.08mm Press Fit ST Thru-Hole

得捷:
TERM BLOCK HDR 6POS VERT 5.08MM

欧时:
Phoenix Contact PCB 接线端子块 COMBICON EMSTBVA 系列 6路 5.08mm节距 1859551, 按式端接, 12A

艾睿:
Reduce the possibility of accidentally shorting pins when using a printed circuit board with this shrouded 1859551 header connector from Phoenix Contact. This HDR connector has 6 contacts that are plated with tin. It has a straight body orientation. It has a header type gender. This is a 1-row connector. Its pitch is 5.08 mm. It has a maximum voltage rating of 320 V. This device has a maximum current rating of 12 A. This product is 32.48 mm long, 12 mm tall and 8.6 mm deep. It uses the press fit termination method. 1859551 is housed in green polybutylene terephthalate.

Verical:
Conn Shrouded Header HDR 6 POS 5.08mm Press Fit ST Thru-Hole

MASTER:
PCB headers - nominal current: 12 A - rated voltage III/2: 320 V - nominal cross section: 2.5 mm² - number of positions: 6 - pitch: 5.08 mm - color: green - contact surface: Tin - mounting: Press-in technology - pin layout: Linear pinning - solder pin [

Online Components:
Conn Shrouded Header HDR 6 POS 5.08mm Press Fit ST Thru-Hole

Electro Sonic:
PCB headers - nominal current: 12 A - rated voltage III/2: 320 V - nominal cross section: 2.5 mm² - ...
