Conn Shrouded Header HDR 6POS 5.08mm Solder RA Thru-Hole
6 针位端子块 接头，公引脚，带罩（2 面） 0.200"（5.08mm） 90°，直角 - 通孔
得捷:
TERM BLOCK HDR 6POS 90DEG 5.08MM
艾睿:
Think of Phoenix Contact&s;s shrouded 1735840 header connector the next time you&s;re concerned about accidentally shorting out pins on your printed circuit. This HDR connector has 6 contacts that are plated with tin. It has a maximum voltage rating of 320 V. Its pitch is 5.08 mm. This is a 1-row connector. It has a header type gender. It has a right angle body orientation. This device has a maximum current rating of 12 A. 1735840 is housed in green polybutylene terephthalate. It uses the solder termination method. This product is 30.48 mm long, 12.4 mm tall and 12 mm deep.
Verical:
Conn Shrouded Header HDR 6 POS 5.08mm Solder RA Thru-Hole
MASTER:
PCB headers - nominal current: 12 A - rated voltage III/2: 320 V - nominal cross section: 2.5 mm² - number of positions: 6 - pitch: 5.08 mm - color: green - contact surface: Tin - mounting: Wave soldering - pin layout: Linear pinning - solder pin [P]: 3
Online Components:
Conn Shrouded Header HDR 6 POS 5.08mm Solder RA Thru-Hole
Electro Sonic:
PCB headers - nominal current: 12 A - rated voltage III/2: 320 V - nominal cross section: 2.5 mm² - ...
