PTPM 和 PTSM 插头连接器管座，适用于 THR 应用适合与 PTPM 连接器一起使用，请参见典型库存号 712-4447 适合与 PTSM 连接器一起使用，请参见典型库存号 712-4471 ### 2.5 mm 推入式支脚弹簧 - Phoenix Contact
Contact COMBICON PTSM 2.5mm 印刷电路板端子块管座
PTSM 系列的专业 2.5 mm 节距管座，在具有空间限制问题时提供紧凑且可靠的连接。
2.5 mm 节距
板对板
通孔安装
提供各种位置
白色
### Phoenix Contact COMBICON 2.5mm 两件式端子块
得捷:
TERM BLOCK HDR 3POS 90DEG 2.5MM
欧时:
Phoenix Contact PCB 接线端子块 COMBICON PTSM 系列 3路 2.5mm节距 1排 直角 1778638, 焊接端接, 6A
贸泽:
可插拔接线端子 PTSM 0,5/ 3-HH-2,5- THR R32
艾睿:
Use this shrouded 1778638 header connector from Phoenix Contact where IDC ribbon cables are used. This HDR connector has 3 contacts that are plated with tin. This is a 1-row connector. Its pitch is 2.5 mm. It has a maximum voltage rating of 160 V. It has a header type gender. It has a right angle body orientation. This device has a maximum current rating of 6 A. It uses the solder termination method. 1778638 is housed in black liquid crystal polymer. This product is 9.2 mm long, 5 mm tall and 7.5 mm deep.
Allied Electronics:
Conn; TermBlk; PCB; Header; SnglLvl; SMT; Sldr; 3Pole; 2.5mmPitch; COMBICONSeries
Verical:
Conn Shrouded Header HDR 3 POS 2.5mm Solder RA Thru-Hole T/R
MASTER:
PCB headers - nominal current: 6 A - rated voltage III/2: 160 V - nominal cross section: 0.5 mm² - number of positions: 3 - pitch: 2.5 mm - color: black - contact surface: Tin - mounting: THR soldering - pin layout: Linear pinning - solder pin [P]: 2.1
Online Components:
Conn Shrouded Header HDR 3 POS 2.5mm Solder RA Thru-Hole T/R
Electro Sonic:
PCB headers - nominal current: 6 A - rated voltage III/2: 160 V - nominal cross section: 0.5 mm² - ...
