1766343

Pluggable Terminal Blocks 2POS 7.5mm pitch Through Hole Header

2 针位端子块 接头，公引脚，带罩（4 面） 0.295"（7.50mm） 90°，直角 - 通孔

得捷:
TERM BLOCK HDR 2POS 90DEG 7.5MM

贸泽:
Pluggable Terminal Blocks 2 Pos 7.5mm pitch Through Hole Header

艾睿:
Mounting this shrouded 1766343 header connector from Phoenix Contact to your printed circuit board can help you support multiple physical configuration options. This HDR connector has 2 contacts that are plated with tin. This is a 1-row connector. Its pitch is 7.5 mm. It has a maximum voltage rating of 630 V. It has a header type gender. It has a right angle body orientation. This device has a maximum current rating of 12 A. This product is 15 mm long, 8.6 mm tall and 12 mm deep. 1766343 is housed in green polyamide. It uses the solder termination method.

Allied Electronics:
Conn; TermBlk; PCB; Header; SnglLvl; 90DegAngl; Sldr; 2Pole; 7.5mmPitch; COMBICON

Verical:
Conn Shrouded Header 4 Sides HDR 2 POS 7.5mm Solder RA Thru-Hole

MASTER:
PCB headers - nominal current: 12 A - rated voltage III/2: 630 V - nominal cross section: 2.5 mm² - number of positions: 2 - pitch: 7.5 mm - color: green - contact surface: Tin - mounting: Wave soldering - pin layout: Linear pinning - solder pin [P]: 3.

Online Components:
Conn Shrouded Header HDR 2 POS 7.5mm Solder RA Thru-Hole

Electro Sonic:
PCB headers - nominal current: 12 A - rated voltage III/2: 630 V - nominal cross section: 2.5 mm² - ...
