1792029

Conn Terminal Block F 3POS 5mm Screw ST Cable Mount 12A

3 针位端子块 插头，母插口 0.197"（5.00mm） - 90° 自由悬挂

得捷:
TERM BLOCK PLUG 3POS 90DEG 5MM

欧时:
Plug-in connector, 5mm pitch, 3 way

艾睿:
Know that you will have strong connections between circuits when you use Phoenix Contact&s;s 1792029 PCB terminal block. This F connector has 3 contacts that are plated with tin. This is a 1-row connector. Its pitch is 5 mm. It has a female type gender. It has a maximum voltage rating of 250 V@IEC|300V@UL. It has a straight body orientation. 1792029 is housed in polyamide. This device has a maximum current rating of 12@IEC|10@UL A. This product is 15 mm long, 26 mm tall and 12.6 mm deep. Its wire is 12-24@IEC|12-30@UL AWG. It uses the screw termination method.

Allied Electronics:
Conn; Term Blk; Plug; Screw; 3; 5 mm; 30-12 AWG; 10 A; 300 V; PA

Verical:
Conn Terminal Block F 3 POS 5mm Screw ST Cable Mount 12A

MASTER:
PCB connector - nominal current: 12 A - rated voltage III/2: 320 V - nominal cross section: 2.5 mm² - number of positions: 3 - pitch: 5 mm - connection method: Screw connection with tension sleeve - color: green - contact surface: Tin

Online Components:
Conn Terminal Block F 3 POS 5mm Screw ST Cable Mount 12A

Electro Sonic:
PCB connector - nominal current: 12 A - rated voltage III/2: 320 V - nominal cross section: 2.5 mm² - ...
