1827826

间距3.81 14位 插头 带锁紧螺丝 8A 160V 螺钉式 配线28-16AWG0.14-1.5mm²

14 Position Terminal Block Plug, Female Sockets 0.150" 3.81mm 180° Free Hanging In-Line

得捷:
TERM BLOCK PLUG 14POS STR 3.81MM

艾睿:
Keep your connections strong with this 1827826 PCB terminal block from Phoenix Contact utilizing clamps and screws. This F connector has 14 contacts that are plated with tin. Its pitch is 3.81 mm. It has a maximum voltage rating of 160 V. It has a female type gender. It has a right angle body orientation. This is a 1-row connector. This device has a maximum current rating of 8 A. 1827826 is housed in polyamide. This product is 63.73 mm long, 11.1 mm tall and 16.1 mm deep. It uses the screw termination method. Its wire is 16-28 AWG.

Allied Electronics:
MINI COMBICON MC SER 3.81mm Pitch Straight Pluggable Trm Blk, Plug w/ Screw Term

Verical:
Conn Terminal Block F 14 POS 3.81mm Screw RA Panel Mount 8A

MASTER:
PCB connector - nominal current: 8 A - rated voltage III/2: 160 V - nominal cross section: 1.5 mm² - number of positions: 14 - pitch: 3.81 mm - connection method: Screw connection with tension sleeve - color: green - contact surface: Tin

Electro Sonic:
PCB connector - nominal current: 8 A - rated voltage III/2: 160 V - nominal cross section: 1.5 mm² - ...
