Phoenix Contact PCB 接线端子块 COMBICON GMSTBA 系列 2路 7.62mm节距 1728853, 焊接端接, 16A
2 针位端子块 接头，公引脚，带罩（4 面） 0.300"（7.62mm） 90°，直角 - 通孔
得捷:
TERM BLOCK HDR 2POS 90DEG 7.62MM
欧时:
Phoenix Contact PCB 接线端子块 COMBICON GMSTBA 系列 2路 7.62mm节距 1728853, 焊接端接, 16A
立创商城:
7.62mm 排数:1 每排P数:2
艾睿:
Easily mount this shrouded 1728853 header connector from Phoenix Contact onto your PCB project to support a variety of physical configuration options. This HDR connector has 2 contacts that are plated with tin. This is a 1-row connector. It has a maximum voltage rating of 630 V. It has a right angle body orientation. It has a header type gender. Its pitch is 7.62 mm. This device has a maximum current rating of 16 A. 1728853 is housed in green polyamide. It uses the solder termination method. This product is 15.24 mm long, 8.6 mm tall and 12 mm deep.
MASTER:
Conn Shrouded Header HDR 2 POS 7.62mm Solder RA Thru-Hole
Online Components:
Conn Shrouded Header HDR 2 POS 7.62mm Solder RA Thru-Hole
Electro Sonic:
PCB headers - nominal current: 16 A - rated voltage III/2: 630 V - nominal cross section: 2.5 mm² - ...
