1803552

间距3.81mm 15位 插座 8A 160V 直插

8A 160V Soldering Mount 11 Position Header

* 15 Position header

* 8 A Nominal current

* 160 V Rated voltage

* 3.81 mm Pitch

* Soldering mount

* Polyamide Insulating Material

* Voltage: 300 V, Amps: 8 A

得捷:
TERM BLOCK HDR 15POS VERT 3.81MM

立创商城:
3.81mm 排数:1 每排P数:15

贸泽:
Pluggable Terminal Blocks 15 Pos 3.81mm pitch Through Hole Header

艾睿:
Reduce safety concerns with this wire to board 1803552 header connector from Phoenix Contact which will reduce the possibility of accidentally shorting pins when a printed circuit board is being used. This HDR connector has 15 contacts that are plated with tin. This is a 1-row connector. It has a straight body orientation. It has a maximum voltage rating of 160 V. Its pitch is 3.81 mm. It has a header type gender. This device has a maximum current rating of 8 A. 1803552 is housed in green polybutylene terephthalate. This product is 62.35 mm long, 9.2 mm tall and 7.25 mm deep. It uses the solder termination method.

Allied Electronics:
Conn; TermBlk; PCB; Header; SnglLvl; Sldr; 15Pole; 3.81mmPitch; COMBICON

Verical:
Conn Wire to Board HDR 15 POS 3.81mm Solder ST Thru-Hole

MASTER:
PCB headers - nominal current: 8 A - rated voltage III/2: 160 V - nominal cross section: 1.5 mm² - number of positions: 15 - pitch: 3.81 mm - color: green - contact surface: Tin - mounting: Wave soldering - pin layout: Linear pinning - solder pin [P]: 3

Online Components:
Conn Wire to Board HDR 15 POS 3.81mm Solder ST Thru-Hole

Electro Sonic:
PCB headers - nominal current: 8 A - rated voltage III/2: 160 V - nominal cross section: 1.5 mm² - ...
