1910380

Conn; Term Blk; PCB; Plug; Spring cage; 5; 5mm; 24-12AWG; Green; 12A; 250V

Contacts Spring Cage Plug Connector

**Features**

* Fast Conductor Connection Through Push-In Direct Plug-In Method

* Can Be Combined with the MSTB 2.5 Range

* Contacting of Solid or Stranded Conductors with a Ferrule without Operating the Opening Lever Directly in the Terminal Point

* Two Test Point Connections

得捷:
TERM BLOCK PLUG 5POS STR 5MM

贸泽:
Pluggable Terminal Blocks 5 Pos 5mm pitch Plug 24-12AWG Spring

艾睿:
This spring cage 1910380 PCB terminal block manufactured from Phoenix Contact will bridge different sections of wires together. This F connector has 5 contacts that are plated with tin. It has a straight body orientation. Its pitch is 5 mm. It has a female type gender. This is a 1-row connector. It has a maximum voltage rating of 320 V. This device has a maximum current rating of 12 A. 1910380 is housed in polyamide. Its wire is 12-24 AWG. This product is 25.1 mm long, 15 mm tall and 25.6 mm deep.

Allied Electronics:
Conn; Term Blk; PCB; Plug; Spring cage; 5; 5 mm; 24-12 AWG; Green; 12 A; 250 V

Verical:
Conn Spring Cage F 5 POS 5mm ST Cable Mount 12A

MASTER:
PCB connector - nominal current: 12 A - rated voltage III/2: 320 V - nominal cross section: 2.5 mm² - number of positions: 5 - pitch: 5 mm - connection method: Push-in spring connection - color: green - contact surface: Tin

Online Components:
Conn Spring Cage F 5 POS 5mm ST Cable Mount 12A

Electro Sonic:
PCB connector - nominal current: 12 A - rated voltage III/2: 320 V - nominal cross section: 2.5 mm² - ...
