1792595

可插拔接线端子 5.00 9P PLUG 270D

9 针位端子块 插头，母插口 0.197"（5.00mm） - 270° 自由悬挂

得捷:
TERM BLOCK PLUG 9POS 270DEG 5MM

贸泽:
可插拔接线端子 5.00 9P PLUG 270D

艾睿:
Keep your connections strong with this 1792595 PCB terminal block from Phoenix Contact utilizing clamps and screws. This F connector has 9 contacts that are plated with tin. It has a straight body orientation. Its pitch is 5 mm. This is a 1-row connector. It has a female type gender. It has a maximum voltage rating of 320 V. This device has a maximum current rating of 12 A. 1792595 is housed in polyamide. Its wire is 12-24 AWG. It uses the screw termination method. This product is 45 mm long, 26 mm tall and 12.6 mm deep.

Allied Electronics:
Conn; Term Blk; Plug; Screw; 9; 5 mm; 30-12 AWG; 10 A; 300 V; PA

MASTER:
PCB connector - nominal current: 12 A - rated voltage III/2: 320 V - nominal cross section: 2.5 mm² - number of positions: 9 - pitch: 5 mm - connection method: Screw connection with tension sleeve - color: green - contact surface: Tin

Online Components:
Conn Terminal Block F 9 POS 5mm Screw ST Cable Mount 12A

Electro Sonic:
PCB connector - nominal current: 12 A - rated voltage III/2: 320 V - nominal cross section: 2.5 mm² - ...
