Phoenix Contact PCB 接线端子块 COMBICON MSTB 系列 18路 5.08mm节距 1776663, 焊接端接, 12A
18 针位端子块 接头，公引脚，带罩（4 面） 0.200"（5.08mm） 90°，直角 - 通孔
得捷:
TERM BLOCK HDR 18POS 5.08MM
欧时:
Phoenix Contact PCB 接线端子块 COMBICON MSTB 系列 18路 5.08mm节距 1776663, 焊接端接, 12A
贸泽:
Pluggable Terminal Blocks 18 Pos 5.08mm pitch Through Hole Header
艾睿:
Phoenix Contact&s;s shrouded 1776663 header connector is a great way to reduce safety concerns in projects where there is a possibility of accidentally shorting electronic components. This HDR connector has 18 contacts that are plated with tin. Its pitch is 5.08 mm. It has a right angle body orientation. It has a header type gender. This is a 1-row connector. It has a maximum voltage rating of 320 V. This device has a maximum current rating of 12 A. This product is 101.6 mm long, 8.6 mm tall and 12 mm deep. It uses the solder termination method. 1776663 is housed in green polybutylene terephthalate.
MASTER:
PCB headers - nominal current: 12 A - rated voltage III/2: 320 V - nominal cross section: 2.5 mm² - number of positions: 18 - pitch: 5.08 mm - color: green - contact surface: Tin - mounting: Wave soldering - pin layout: Linear pinning - solder pin [P]:
Online Components:
Conn Shrouded Header HDR 18 POS 5.08mm Solder RA Thru-Hole
Electro Sonic:
PCB headers - nominal current: 12 A - rated voltage III/2: 320 V - nominal cross section: 2.5 mm² - ...
