间距7.62mm 4位 母座 12A 630V 弯插 无封边
4 针位端子块 接头，公引脚，带罩（2 面） 0.300"（7.62mm） 90°，直角 - 通孔
得捷:
TERM BLOCK HDR 4POS 90DEG 7.62MM
贸泽:
可插拔接线端子 4 Pos 7.62mm pitch Through Hole Header
艾睿:
Reduce the possibility of accidentally shorting pins when using a printed circuit board with this shrouded 1766149 header connector from Phoenix Contact. This HDR connector has 4 contacts that are plated with tin. It has a header type gender. This is a 1-row connector. It has a maximum voltage rating of 630 V. Its pitch is 7.62 mm. It has a right angle body orientation. This device has a maximum current rating of 12 A. It uses the solder termination method. 1766149 is housed in green polyamide. This product is 28.68 mm long, 8.6 mm tall and 12 mm deep.
MASTER:
Conn Shrouded Header HDR 4 POS 7.62mm Solder RA Thru-Hole
Online Components:
Conn Shrouded Header HDR 4 POS 7.62mm Solder RA Thru-Hole
Electro Sonic:
PCB headers - nominal current: 12 A - rated voltage III/2: 630 V - nominal cross section: 2.5 mm² - ...
