1795556

1795556图片1
1795556图片2
1795556图片3
1795556概述

Conn Terminal Block F 2POS 5.08mm Screw RA Panel Mount 12A

Conn Terminal Block F 2 POS 5.08mm Screw RA Panel Mount 12A


得捷:
TERM BLOCK PLUG 2POS STR 5.08MM


MASTER:
PCB connector - nominal current: 12 A - nominal cross section: 2.5 mm² - number of positions: 2 - pitch: 5.08 mm - connection method: Screw connection with tension sleeve - color: green - contact surface: Tin


Online Components:
Conn Terminal Block F 2 POS 5.08mm Screw RA Panel Mount 12A


Electro Sonic:
PCB connector - nominal current: 12 A - nominal cross section: 2.5 mm² - number of positions: 2 - pitch: ...


1795556中文资料参数规格
技术参数

触点数 2

线规 12AWG ~ 24AWG

触点电镀 Silver

排数 1

电路数 2

针脚数 2

额定电流Max 12 A

额定电压Max 176 V

封装参数

安装方式 Screw

外形尺寸

长度 18.2 mm

物理参数

外壳颜色 Green

颜色 Green

其他

产品生命周期 Active

符合标准

RoHS标准 RoHS Compliant

含铅标准 Lead Free

海关信息

ECCN代码 EAR99

HTS代码 8536694040

数据手册

在线购买1795556
型号: 1795556
描述:Conn Terminal Block F 2POS 5.08mm Screw RA Panel Mount 12A
