1996142

Phoenix Contact COMBICON SPC 系列 7.62mm 节距 4 路 母 绿色 插头 1996142, 弹簧笼端接

Conn Spring Cage F 4 POS 7.62mm ST Panel Mount 41A

得捷:
TERM BLOCK PLUG 4POS STR 7.62MM

欧时:
Phoenix Contact COMBICON SPC 系列 7.62mm 节距 4 路 母 绿色 插头 1996142, 弹簧笼端接

贸泽:
可插拔接线端子 4 Pos 7.62mm pitch Plug 24-8 AWG Spring

艾睿:
This spring cage 1996142 PCB terminal block from Phoenix Contact will join multiple circuits by connecting to the bare wire. This F connector has 4 contacts that are plated with tin. It has a straight body orientation. Its pitch is 7.62 mm. It has a maximum voltage rating of 1000 V. It has a female type gender. This is a 1-row connector. 1996142 is housed in polyamide. This device has a maximum current rating of 41 A. Its wire is 8-24 AWG. This product is 45.7 mm long, 19.8 mm tall and 38.5 mm deep.

Verical:
Conn Spring Cage F 4 POS 7.62mm ST Panel Mount 41A

MASTER:
PCB connector - nominal current: 41 A - rated voltage III/2: 1000 V - nominal cross section: 6 mm² - number of positions: 4 - pitch: 7.62 mm - connection method: Push-in spring connection - color: green - contact surface: Tin

Online Components:
Conn Spring Cage F 4 POS 7.62mm ST Panel Mount 41A

Electro Sonic:
PCB connector - nominal current: 41 A - rated voltage III/2: 1000 V - nominal cross section: 6 mm² - ...
