Phoenix Contact PCB 接线端子块 COMBICON MSTBV 系列 24路 5mm节距 1753877, 焊接端接, 12A
Conn Shrouded Header HDR 24 POS 5mm Solder ST Thru-Hole
得捷:
TERM BLOCK HDR 24POS VERT 5MM
欧时:
Phoenix Contact PCB 接线端子块 COMBICON MSTBV 系列 24路 5mm节距 1753877, 焊接端接, 12A
艾睿:
Mount this shrouded 1753877 header connector from Phoenix Contact on a jumper post on your PCB to support physical configuration options. This HDR connector has 24 contacts that are plated with gold. This is a 1-row connector. It has a maximum voltage rating of 300 V. Its pitch is 5 mm. It has a straight body orientation. It has a header type gender. This device has a maximum current rating of 12 A. 1753877 is housed in green polybutylene terephthalate. This product is 120 mm long, 12 mm tall and 8.6 mm deep. It uses the solder termination method.
MASTER:
PCB headers - nominal current: 12 A - rated voltage III/2: 320 V - nominal cross section: 2.5 mm² - number of positions: 24 - pitch: 5 mm - color: green - contact surface: Tin - mounting: Wave soldering - pin layout: Linear pinning - solder pin [P]: 3.9
Online Components:
Conn Shrouded Header HDR 24 POS 5mm Solder ST Thru-Hole
Electro Sonic:
PCB headers - nominal current: 12 A - rated voltage III/2: 320 V - nominal cross section: 2.5 mm² - ...
