可插拔接线端子 4 Pos 10.16mm pitch Through Hole Header
4 针位端子块 接头，公引脚，带罩（4 面） 0.400"（10.16mm） 垂直 - 通孔
得捷:
TERM BLOCK HDR 4POS VERT 10.16MM
欧时:
PCB header
贸泽:
可插拔接线端子 4 Pos 10.16mm pitch Through Hole Header
艾睿:
Support physical configuration options for jumper posts by mounting this wire to board 1998881 header connector from Phoenix Contact. This HDR connector has 4 contacts that are plated with silver. Its pitch is 10.16 mm. This is a 1-row connector. It has a header type gender. It has a straight body orientation. It has a maximum voltage rating of 1000 V. This device has a maximum current rating of 76 A. It uses the solder termination method. 1998881 is housed in green polyamide. This product is 58.4 mm long, 34 mm tall and 13.4 mm deep.
Verical:
Conn Wire to Board HDR 4 POS 10.16mm Solder ST Thru-Hole
MASTER:
PCB headers - nominal current: 76 A - rated voltage III/2: 1000 V - nominal cross section: 16 mm² - number of positions: 4 - pitch: 10.16 mm - color: green - contact surface: Silver - mounting: Wave soldering - pin layout: Linear pinning - solder pin [P
Online Components:
Conn Wire to Board HDR 4 POS 10.16mm Solder ST Thru-Hole
Electro Sonic:
PCB headers - nominal current: 76 A - rated voltage III/2: 1000 V - nominal cross section: 16 mm² - ...
