Phoenix Contact COMBICON IPC 系列 10.16mm 节距 9 路 母 绿色 反相插头 1969522, 螺钉端接
Conn Terminal Block F 9 POS 10.16mm Screw RA Panel Mount 76A
得捷:
TERM BLOCK PLUG 9POS STR 10.16MM
欧时:
Phoenix Contact COMBICON IPC 系列 10.16mm 节距 9 路 母 绿色 反相插头 1969522, 螺钉端接
贸泽:
可插拔接线端子 9 Pos 10.16mm Invert Plug 18-6AWG Screw
艾睿:
Conn Terminal Block M 9 POS 10.16mm Screw RA Panel Mount 76A
Verical:
Conn Terminal Block M 9 POS 10.16mm Screw RA Panel Mount 76A
MASTER:
PCB connector - nominal current: 76 A - rated voltage III/2: 1000 V - nominal cross section: 16 mm² - number of positions: 9 - pitch: 10.16 mm - connection method: Screw connection with tension sleeve - color: green - contact surface: Silver
Online Components:
Conn Terminal Block F 9 POS 10.16mm Screw RA Panel Mount 76A
Electro Sonic:
PCB connector - nominal current: 76 A - rated voltage III/2: 1000 V - nominal cross section: 16 mm² - ...
触点数 9
线规 6AWG ~ 20AWG
触点电镀 Silver
额定电流 76 A
排数 1
电路数 9
易燃性等级 UL 94 V-0
针脚数 9
额定电流Max 76 A
额定电压Max 1000 V
额定电压 1 kV
工作电压Max 1000 V
安装方式 Screw
长度 44.1 mm
宽度 109.2 mm
高度 44.1 mm
外壳颜色 Green
颜色 Green
外壳材质 Plastic
产品生命周期 Active
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
HTS代码 8536694040
