Phoenix Contact COMBICON FKCVR 系列 5mm 节距 14 路 母 绿色 插头 1909838, 弹簧笼端接
14 Position Terminal Block Plug, Female Sockets 0.197" 5.00mm 90° Free Hanging In-Line
得捷:
TERM BLOCK PLUG 14POS 90DEG 5MM
欧时:
Phoenix Contact COMBICON FKCVR 系列 5mm 节距 14 路 母 绿色 插头 1909838, 弹簧笼端接
艾睿:
Create a bridge between two sides of a circuit by implementing this spring cage 1909838 PCB terminal block from Phoenix Contact. This F connector has 14 contacts that are plated with tin. It has a right angle body orientation. Its pitch is 5 mm. This is a 1-row connector. It has a female type gender. It has a maximum voltage rating of 320 V. 1909838 is housed in polyamide. This device has a maximum current rating of 12 A. Its wire is 12-24 AWG. This product is 70.1 mm long, 16.8 mm tall and 26.6 mm deep.
MASTER:
PCB connector - nominal current: 12 A - rated voltage III/2: 320 V - nominal cross section: 2.5 mm² - number of positions: 14 - pitch: 5 mm - connection method: Push-in spring connection - color: green - contact surface: Tin
